It is used in general industrial fields, such as the process service, Lubricating liquids, aqueous solutions, chemicals, corrosives, some acids. Reduces slippage on shaft and sleeve to eliminate galling and premature wear. Permits use in all types of rotating equipment centrifugal pumps, mixers and agitators.
| Standard Size | 20mm to 150mm |
|---|---|
| Fluid | – |
| Max. Pressure | 30 kgf/cm² |
| Max. Temperature | 180°C |
| Max. Rotating Speed | 5,000 fpm |
| Standard Size | 25mm to 100mm |
|---|---|
| Fluid | – |
| Max. Pressure | 28 kgf/cm² |
| Max. Temperature | 120°C |
| Max. Rotating Speed | 2 m/sec |
| Standard Size | 25mm to 100mm |
|---|---|
| Fluid | – |
| Max. Pressure | 12 kgf/cm² |
| Max. Temperature | 250°C |
| Max. Rotating Speed | 15 m/sec |
| Standard Size | 25mm to 100mm |
|---|---|
| Fluid | – |
| Max. Pressure | 28 kgf/cm² |
| Max. Temperature | 250°C |
| Max. Rotating Speed | 15 m/sec |
| Standard Size | 25mm to 100 mm |
|---|---|
| Fluid | – |
| Max. Pressure | 25 kgf/cm² |
| Max. Temperature | 350°C |
| Max. Rotating Speed | 25 m/sec |
| Standard Size | 20mm to 100mm |
|---|---|
| Fluid | – |
| Max. Pressure | 25 kgf/cm² |
| Max. Temperature | 250°C |
| Max. Rotating Speed | 25 m/sec |
Type CDR seals are outside-mounted ID balanced seals with the seal faces in contact during operation. No auxiliary equipment is required for lubrication. These seals are excellent for operation in vacuum conditions and meet the needs of pharmaceutical and chemical processing industries. For top entering mixers, agitators and reactor vessels.
Type CPD cartridge seals are recommended for hazardous or abrasive applications in which double or tandem seal protection and performance are essential, but only limited installation space is available. Wherever stuffing box space limitations are problems, recommended for a wide variety of services in industries where ANSI pumps are used. May also be used in some API applications with user’s consent.
Type CPS cartridge seals are designed for installations where maximum compactness is needed and where only a single seal is adequate. Wherever stuffing box space limitations are problems, recommended for a wide variety of services in industries where ANSI pumps are used. May also be used in some API applications with user’s consent.
General industrial applications including process services. Lubricating liquids, aqueous solutions, chemicals, corrosives, some acids. Reduces slippage on shaft and sleeve to eliminate galling and premature wear. Permits use in all types of rotating equipment centrifugal pumps, mixers and agitators.
General industrial applications including process services. All industrial chemicals and corrosives, both liquid and gas, such as sulphuric, nitric, phosphoric, or hydrochloric acids. Rugged mechanical seals are available in a wide variety of elastomers for handling practically every industrial fluid. All components are held together by a spacer in a unitized construction design.
| Standard Size | – |
|---|---|
| Fluid | – |
| Max. Pressure | Shell : 10 kgf/cm² Cooling Coil : 30 kgf/cm² |
| Max. Temperature | Shell : 120°C Cooling Coil : 230°C |
| Max. Rotating Speed | – |
